Accordion

Accordion preview

Accordion — a collapsible section with a clickable header that shows or hides its content when activated.

In the default vertical mode a horizontally-spanning header row sits above the content; clicking or pressing Space/Enter toggles visibility with an animated height disclosure (via Collapse). A horizontal mode flips the header into a narrow vertical strip with a rotated label — used by top/bottom sides of a DockingLayout. Fill mode (.fill(true)) is designed for fixed-size slots such as Splitter panes: the content fills all available space and collapse animation is driven externally by the enclosing pane rather than by an internal height tween.

Accessibility

The header is announced as Role::Button with aria-expanded reflecting the current state, and aria-controls pointing at the content region (Role::Region). Space/Enter toggle the disclosure; AT "click" actions are also handled. The focus ring appears only on keyboard focus (not on pointer clicks), matching the IntUI convention.

#![allow(unused)]
fn main() {
use teksilo_widgets::accordion::Accordion;
use teksilo_core::signal::Signal;
use teksilo_i18n::lit;
let expanded = Signal::new(false);
let _accordion = Accordion::new(lit!("Advanced settings"), expanded);
}

Builder methods at a glance

orientation, horizontal, fill, on_header_drag, trailing, trailing_id, title_color, title_style, content_id, content

API reference

📖 Full rustdoc API for this module

`pub const ACCORDION_HEADER_HEIGHT`

Height of the accordion header row in pixels (vertical mode).

#![allow(unused)]
fn main() {
pub const ACCORDION_HEADER_HEIGHT: f32 = 28.0;
}

`pub const ACCORDION_HEADER_PADDING_HORIZONTAL`

Horizontal padding inside the accordion header on the leading and trailing edges.

#![allow(unused)]
fn main() {
pub const ACCORDION_HEADER_PADDING_HORIZONTAL: f32 = 8.0;
}

`pub const ACCORDION_INDICATOR_SIZE`

Size of the chevron disclosure indicator icon in pixels.

#![allow(unused)]
fn main() {
pub const ACCORDION_INDICATOR_SIZE: f32 = 12.0;
}

`pub const ACCORDION_INDICATOR_GAP`

Gap between the disclosure indicator and the title label.

#![allow(unused)]
fn main() {
pub const ACCORDION_INDICATOR_GAP: f32 = 6.0;
}

`pub const ACCORDION_CORNER_RADIUS`

Corner radius of the keyboard-focus ring painted on the accordion header.

#![allow(unused)]
fn main() {
pub const ACCORDION_CORNER_RADIUS: f32 = 4.0;
}

`pub enum AccordionOrientation`

Orientation of an [Accordion]: how its header sits relative to its content. Vertical (the default) is a horizontal header row above the content; Horizontal is a narrow vertical header strip (rotated-90° label, left/right chevron) beside the content — used by top/bottom dock sides.

#![allow(unused)]
fn main() {
pub enum AccordionOrientation { /* variants */ }
}

Variants

Vertical — Header row above the content (default).
Horizontal — Vertical header strip beside the content.

`pub struct Accordion`

A collapsible section widget whose header button shows or hides attached content.

Supply the title and a Signal<bool> for the expanded state, then attach content via .content(w) or .content_id(id). The signal can be toggled externally (e.g. from a "collapse all" button) and the disclosure animation will follow.

#![allow(unused)]
fn main() {
pub struct Accordion { /* fields */ }
}

Methods

`pub fn new(title: impl Into<LocalizedString>, expanded: Signal<bool>) -> Self`

Create a new accordion with the given title and an external expanded signal.

The accordion starts collapsed or expanded according to the initial value of expanded. Toggling the signal later drives the disclosure animation.

`pub fn orientation(mut self, orientation: AccordionOrientation) -> Self`

Set the header orientation (default AccordionOrientation::Vertical).

`pub fn horizontal(mut self) -> Self`

Shorthand for Accordion::orientation``(``AccordionOrientation::Horizontal``).

`pub fn fill(mut self, fill: bool) -> Self`

Make the expanded content fill the accordion's allotted space (the leftover after the header) — instead of the default natural-height disclosure — while keeping the collapse/expand animated. Use when the accordion lives in a fixed-size slot such as a Splitter pane (a dock panel): the content lays out at exactly the available size (no narrow content, no overflow) and the header tween still plays. Default false.

`pub fn on_header_drag(mut self, f: impl Fn(&mut EventContext) + 'static) -> Self`

Make the header a drag source: a drag gesture starting on it fires f (which should begin a drag, e.g. ctx.start_drag(source, payload)). Tap-to-toggle is unaffected — the gesture arena tells a tap from a drag.

Place a widget at the trailing end of the header, before the disclosure chevron — an options (⋮) button, an inline action toolbar, etc. The slot's own controls capture their gestures (innermost hit wins), so clicking them does not toggle the accordion. Mirrors ToolBoxItem::trailing / TabWidget::bar_trailing_slot.
