GroupBox

GroupBox — titled cluster of controls in Int UI / Jewel style.

Public types

Public functions

GroupBox

Detailed description

A bold title (optionally preceded by a checkbox) sits above an indented content area. No border, no frame — pure composition. The standard use is grouping related settings controls on a preferences sheet or form — the IntelliJ "group" pattern.

In checkable mode, unchecking disables event dispatch to every descendant of the content area (via ctx.enabled_when with ancestor propagation) AND paints a translucent surface overlay over the content so it reads as greyed-out. The title checkbox itself stays interactive.

When to use

• GroupBox — logical cluster with a title; optional enable/disable toggle for the whole cluster. Use for settings sections.
• GroupHeader — lighter-weight "soft divider + caption" without a content slot; use to label regions that are not collapsed or disabled as a unit.

Accessibility

The box node carries Role::Group and its name is set to the title string. When checkable and unchecked, set_disabled() is set on the group node so assistive technology announces the cluster as unavailable.

#![allow(unused)]
fn main() {
use teksilo_widgets::GroupBox;
use teksilo_widgets::primitives::TextWidget;
use teksilo_i18n::lit;
let _w = GroupBox::new(lit!("Indentation"))
    .child(TextWidget::new(lit!("Tab width: 4")));
}

Density

The picture above is the widget at TargetDensity::Compact, the mouse-and-keyboard ladder. Below is the same subject on the same canvas with only the ladder changed, so what moves is the density and nothing else — where the subject no longer fits, that is what the denser targets cost it at that size. See docs/density-and-targets.md.

Touch

API reference

📖 Full rustdoc API for this module

pub const GROUP_BOX_CONTENT_INDENT

Import: use teksilo::widgets::group_box::GROUP_BOX_CONTENT_INDENT;

Horizontal indent of the content area below the title (dp).

#![allow(unused)]
fn main() {
pub const GROUP_BOX_CONTENT_INDENT: f32 = 24.0;
}

pub fn group_box_content_indent(...)

Import: use teksilo::widgets::group_box::group_box_content_indent;

GROUP_BOX_CONTENT_INDENT scaled by the density's spacing_factor (1.00 / 1.15 / 1.30).

#![allow(unused)]
fn main() {
pub fn group_box_content_indent(tokens: &InputTokens) -> f32;
}

pub const GROUP_BOX_TITLE_CONTENT_SPACING

Import: use teksilo::widgets::group_box::GROUP_BOX_TITLE_CONTENT_SPACING;

Vertical gap between the title row and the content area (dp).

#![allow(unused)]
fn main() {
pub const GROUP_BOX_TITLE_CONTENT_SPACING: f32 = 8.0;
}

pub fn group_box_title_content_spacing(...)

Import: use teksilo::widgets::group_box::group_box_title_content_spacing;

GROUP_BOX_TITLE_CONTENT_SPACING scaled by the density's spacing_factor (1.00 / 1.15 / 1.30).

#![allow(unused)]
fn main() {
pub fn group_box_title_content_spacing(tokens: &InputTokens) -> f32;
}

pub const GROUP_BOX_CHECKBOX_GAP

Import: use teksilo::widgets::group_box::GROUP_BOX_CHECKBOX_GAP;

Gap between the checkbox and the adjacent title label in checkable mode (dp).

#![allow(unused)]
fn main() {
pub const GROUP_BOX_CHECKBOX_GAP: f32 = 6.0;
}

pub fn group_box_checkbox_gap(...)

Import: use teksilo::widgets::group_box::group_box_checkbox_gap;

GROUP_BOX_CHECKBOX_GAP scaled by the density's spacing_factor (1.00 / 1.15 / 1.30).

#![allow(unused)]
fn main() {
pub fn group_box_checkbox_gap(tokens: &InputTokens) -> f32;
}

pub struct GroupBox

Import: use teksilo::widgets::GroupBox;

A titled cluster of controls with optional enable/disable toggle.

See the module documentation for the checkable-mode details and the GroupHeader sibling.

#![allow(unused)]
fn main() {
pub struct GroupBox { /* fields */ }
}

Methods

pub fn new(title: impl Into<LocalizedString>) -> Self

Create a non-checkable group box with the given title.

pub fn checkable(mut self, checked: Signal<bool>) -> Self

Turn this into a checkable GroupBox. When the signal is false, events to descendants of the content area are blocked via effective-enabled ancestor propagation. The title checkbox itself stays interactive.

pub fn child(mut self, widget: impl teksilo_core::IntoTeksiChild) -> Self

Set the content widget inline (deferred insertion).

pub fn child_opt(self, widget: Option<impl teksilo_core::IntoTeksiChild>) -> Self

Attach widget when it is Some, and do nothing when it is None.

The conditional-child form. teksu!'s if without an else lowers to this, and it is what cond.then(|| w) is for in a builder chain. None adds no arena node, so nothing is laid out, painted, or published to the accessibility tree, and a stack applies no spacing around it.
